PS5 PlayStation 5 broken HDMI port replacement in Hamilton New zealand. Eventhough we have repaired 100s of ps4 broken hdmi port and initially i thought in playstation 5 they might comeup with a better design hdmi port which is more rugged and not easy to snip off but hdmi port on pst is as fragine as it was in previous generation of playstation. in this video i have demonstrated how to open ps5 and desolder hdmi port and microsoldering new on ps5. AppleFix New Zealand are playstation and xbox repair experts in hamilton new zealand any problem with your xbox or playstation bring it to applefix nz 125 ward street hamilton.

Playstation 5 TearDown

The opening procedure is actually quite easy. Both panels pop off with a gentle lift and this gives you access to M.2 ssd slot

Next you need a T8 Torx screw driver, once these screws are removed you can pull black housing whci will give further access to optical drive. Next you have to remove tons of screws to remove the metal sheet. Underneath metal sheet massive heatsink and power supply. Now we can easily remove ps5 logicboard and look the hdmi port under microscope

playstation 5 ps5 hdmi port replacement teardown hamilton new zealand

watch full teardown video and hdmi port repair on pst at below link

PS5 PlayStation 5 broken HDMI port replacement in Hamilton New zealand. Eventhough we have repaired 100s of ps4 broken hdmi port and initially i thought in playstation 5 they might comeup with a better design hdmi port which is more rugged and not easy to snip off but hdmi port on pst is as fragine as it was in previous generation of playstation. in this video i have demonstrated how to open ps5 and desolder hdmi port andf microsoldering new on ps5. AppleFix New Zealand are playstation and xbox repair experts in hamilton new zealand any problem with your xbox or playstation bring it to applefix nz 125 ward street hamilton

if you dont live in hamilton you can send your playstation in the courier read full send your device info here

Microsoldering & Logicboard repair courses in New Zealand

Skill development Job Oriented short Training course. In Latest Gadgets, Smart Mobile Phones, Tablets, Laptops, Desktops, gaming gadget, Playstation, Xbox Repair Technology.

This course is aimed / focused, to teach you to fix most common repairs an electronics repair shop could face in a practical working environment.  Start your own business or increase your chances to get job quickly. Read courses info here



Iphone 12, 12 Pro Broken Screen Replacement

The Apple Fix service center agency is one of the best iPhone 12, 12 Pro Broken Screen Replacement centers in New Zealand with no issues on quality of service. As you know genuine iPhone parts and items aren’t available at all service centers and they usually put third-party displays that only make the phone go bad or even worse. The agency has a wide range of service experience along with great knowledge of practical iPhone repairs of any kind. The technicians available at Apple Fix are full professional experts in repairing any sort of problem in your iPhone even if it is a mild iPhone 12, 12 Pro Broken Screen Replacement job. They are also well experts in repairing most Apple products including Macbooks, iMac, and also Mac Pro computers.

Iphone screen repair

The Apple Fix agency provides completely genuine and original parts from their service center repair works at low-cost prices. The service provider also leads all other kinds of repair services including iPhone repairs, iPad repairs, iPod repairs, mac, and MacBook repairs, Samsung Phone Repairs, mobile phone repairs, laptop repairs, and also gaming consoles repairs like Xbox, PlayStation and Nintendo, and other Machines. The services offered are well recommended and renowned in New Zealand due to Apple Fix’s quick solutions as well as replacement works as well as timed delivery. The service center is also reliable in fixing common iPhone 12, 12 pro-OS issues, tactical issues, and other kinds of user generated problems at no extra charges at all.

The available alternate service centers aren’t as fluent as Apple Fix service remarks due to their high cost of service and less efficiency of work. Searching for the best iPhone 12, 12 Pro Broken Screen Replacement agencies in New Zealand at low prices? The Apple Fix Service Center is incredibly capable and experienced to provide great solutions to your iPhone 12, 12 pro broken screen repairs as well as providing genuine parts at affordable prices.

iphone rear camera not working camera ic replacement

iphone rear camera not working camera ic replacement Hamilton nz

iphone rear camera not working camera ic replacement hamilton nz

This blog is about if your iphone rear camera not working camera ic replacement hamilton nz at our lab in hamilton new zealand. This iphone sent us from one of our dealers they replaced with known working camera but still rear camera on this iphone failed to work.

After removing the logic board we find out the iphone is water damaged. Even though logic board gone through ultrasonic clean but still rear camera failed to initialized. From my experience  the moisture or liquid damaged formed and accumulated under the IC is hard to remove by ultrasonic clean. Further more is there is a hardware short it cant be removed by just ultrasonic clean. The IC has to be removed and replaced with new one.

iphone repair experts in hamilton new zeland

AppleFix hamilton are iphone repair specialist in new zealand. With state of art art iphone repair facility in store we can repair any hardware and software problem instore. Once iphone camera ic is removed it shows one of the pad under the ic was corroded. Iphone camera ic is one of the smallest ics on the iphone motherboard.

Watch iphone camera ic replacement full video below



After removing camera ic from the logicboard the pads were cleaned and tinted with solder paste so that they can make good connection with new ic. This sort of iphone logic board repair or iphone water damage repair requires soldering skills. If you have this kind of problem on your iphone front or rear camera is not working you can either bring it to 125 ward street hamilton new zealand. if you dont live in new zealand read send your device instruction here

We also offer logicboard repair courses in New Zealand.

Skill development Job Oriented short Training course. In Latest Gadgets, Smart Mobile Phones, Tablets, Laptops, Desktops, gaming gadget, Playstation, Xbox Repair Technology.

This course is aimed / focused, to teach you to fix most common repairs an electronics repair shop could face in a practical working environment.  Start your own business or increase your chances to get job quickly. To Find out more click here

IPHONE REPAIR HAMILTON,  MATAMATA,  CAMBRIDGE,  RAGLAN,  TE AWAMUTU,  HUNTLY,  MORRINSVILLE,  NGĀRUAWĀHIA



iphone dead repair, how to find faulty component or short on iphone logic board

iphone dead repair, how to find faulty component or short on iphone logic board

iphone dead repair, how to find faulty component or short on iphone logic board @ AppleFix Hamilton New Zealand

In this video i have shown iphone dead repair, how to find faulty component or short on iphone logic board Not just one but there were multiple problems on this iphone. There are several ways to find the faulty or shorted component on the iphone logic borad. But before i go into details of how to find a short on the logic board or any logic board it is important to know what a “short” means in electronics.

short circuit on PCB board refers to a condition in which electricity strays outside the established pathway of an electrical circuit. A short circuit happens when electrical flow completes its circuit journey via a shorter distance than is present in the established. On iphones there are two types of short ” in put short” and ” output short”. In most cases if the iphone is not liquid damaged usually it is a burnt capacitor that can create short on the iphone.

How to find shorted component on iphone logic board.

There are different ways you can find a shorted component on iphone logic board. The most commonly used method is supplying power to logic board with external power supply and check or feel with your hands where the log board is heating. With this method it is pretty hard to determine exactly which component is heating because there are components which you can see clearly on under microscope.

Isopropyl alcohol is easily available solution and can help to find which component  is heating. You can also use freeze spray which is shown in the video.

If both of above methods fail to conclude or find the faulty module or part. Thermal camera is best solution as shown in the video.. Watch the below video to learn how to uses, isopropyle, freeze or thermal camera method to find short on PCB board

iphone dead repair, how to find faulty component or short on iphone logic board

you can find another blog and video on iphone repair here

Expert iphone repair in Hamilton New Zealand.

AppleFix Hamilton New Zealand at 125 ward street hamilton New Zealand are iphone repair experts. get your iphone fixed by iphone repair experts, Call 078394188

Microsoldering & Logic Board Repair Courses

Visit and subscribe our youtube Channel for live Logic Board Repair

https://www.youtube.com/c/ApplefixCoNz

Skill development Job Oriented short Training course. In Latest Gadgets, Smart Mobile Phones, Tablets, Laptops, Desktops, gaming gadget, Playstation, Xbox Repair Technology.

This course is aimed / focused, to teach you to fix most common repairs an electronics repair shop could face in a practical working environment.  Start your own business or increase your chances to get job quickly.

iphone dead repair, how to find faulty component or short on iphone logic board

iphone dead repair, how to find faulty component or short on iphone logic board

Macbook Pro Retina A1502 dead logic board repair New Zealand

Macbook Pro Retina A1502 dead logic board repair New Zealand

Macbook Pro Retina A1502 dead logic board repair New Zealand

AppleFix New zealand are macbook repair experts in New Zealand in this blog we will demonstrated Macbook Pro Retina A1502 dead logic board repair New Zealand. This Macnook pro showing charging light on magsafe but fan not spinning.

We tested volts on magsafe and getting right voltage and nothing wrong with dc jack it suppling correct voltages. In this case first thing to do is to check the power rails from schematic diagram. Because magsafe charger light is turning on from green to yellow that means adapter sense is working but cpu not turning on so thus gives us idea that cpu vcore line might be faulty.

We checked ppvcc_s0_cpu we checked R7320 where we should get 1.5V but there is no volts on cpu rail. We find short on CPU vcore line. Having short on cpu line means macbook will not turn on.

Macbook Pro Retina A1502 dead logic board repair New Zealand

Next thing to do is to find which part on cpu vcore line is faulty and creating the short? I also recommend not to clean a water damage macbook board before you examine it. Ultrasonic cleaning will wash any evidence which can make repair easier. I find C7374 capacitor little bit of moisture and sticky substance by one side of it. This gave me little bit of indication that this capacitor may be faulty. From schematic diagram i confirm this is same line ppvcc_s0_cpu.

MacBook Logicboard repairs in hamilton new zealand at AppleFix

I removed the suspected capacitor and tested with multimeter and short is gone. Got the same capacitor from a donor board soldered it back and macbook wturns on and fixed.

If your macbook is dead and you have been told it is not fixable it is worth trying with us. We also offer logic board repair courses.

Skill development Job Oriented short Training course. In Latest Gadgets, Smart Mobile Phones, Tablets, Laptops, Desktops, gaming gadget, Playstation, Xbox Repair Technology.

This course is aimed / focused, to teach you to fix most common repairs an electronics repair shop could face in a practical working environment.  Start your own business or increase your chances to get job quickly.

Find more info on logicboard repair courses here

Watch full repair video on above repair



Visit applefix 125 ward street hamilton call 078394188











Ipad pro 9.7 A1673 charging port & charging ic replacement

Ipad Pro 9.7 A1673 charging port & charging ic replacement

Ipad Pro 9.7 A1673 charging port & charging ic replacement

Ipad pro 9.7 A1673 charging port & charging ic replacement @Applefix Hamilton New Zealand. We have to check it before replacing that it’s a charging port or charging ic faulty. So, firstly we have to check the board diagram that how much voltage ipad need to charge and then check with multimeter. We got 3.8V rather than 5V which is not sufficient to charge the ipad.

We are not getting the right voltage so we first will replace the charging port and check it how it goes. Ipad Pro 9.7 A1673 charging port are micro soldering. If you have similar problems please bring your ipad at Applefix Hamilton.

How to remove and solder the new charging port on iPad Pro 9.7 A1673 ?

First thing what we will be doing is to tint the pads. Why we are tinting these pads so that we will bring the temperature down . It’s easy to melt them when we are taking it out. Then tint the pads. After that set the right temperature to remove the charging port. Please be patient while removing it don’t pull it hard. It will come out easily if you are using the right temperature.

Next thing what we will be doing is solder break so that we will clean the pads. Put isopropyl alcohol and clean it. Make sure there is no glue left and cleaned properly. Put the new charging port & some flex and solder it back.

Now we have to check it again how much voltage we are getting after replacing the charging port. We are getting the same voltage that is 3.8V. So there is no difference even after replacing it. Next step is to replace the u2 ic or charging ic (part no. 1610A3).

You can watch some more information on same kind of repair here

Find our another blog on Ipad repair here



How to replace the U2 ic 1610A3 ?

First, find out where the u2 ic is. Then, put some flex and set the right temperature to remove the u2 ic part no. A1610A3.  After removing the charging ic do solder break. Then put little bit of solder paste and clean with isopropyl alcohol. Before replacing it, cover the components near the charging ic. Put some flex and take out the new charging ic and set the right temperature and solder it. Give a proper clean after putting the new U2 ic.

After replacing the u2 ic, now check it again with multimeter how much voltage we are getting. Now are getting exact 5V that means u2 ic was faulty. We are getting the right voltage after replacing the charging ic.

If you are interested in learning these sorts of repair or you have any ipad which have charging port problem you can contact us.

Get your Ipad fixed by professional at AppleFix Hamilton New Zealand or call now for free quote 125 ward street Hamilton.

Macbook pro A1708 dead, Type C power IC replacement

Macbook pro A1708 dead, Type C power IC replacement new zealand

Macbook pro A1708 dead, Type C power IC replacement Hamilton New Zealand

Macbook pro A1708 no power Type C power IC repair @AppleFix New Zealand. These Macbook having problems, they just go dead. What’s wrong with it? There are different ways to check it. So, let’s start how to diagnose the problem. Macbook pro A1708 dead, Type C power IC replacement.

How we will diagnose the problem?

The best way to get an idea what could be wrong with newer type Macbook which have Type C dc jack. Firstly, we have to check with type C amp meter, it was showing only 5V output but the right output is 19V . That means there is something wrong with it.

Secondly, we have to check Type C power management IC U3200 with Multimeter which is located near the type C dc jack. You can see clearly in our YouTube video.



We have to put the multimeter in continuity mode. Then we will check the capacitors one which is on the ground and one is on the line. We are getting beep on two capacitors which is not right. Check where these capacitors were attached. The Type C Power ic U3200 is directly attached to the U2890. If PP3V3 line is shorted which is coming from U3200 that’s why we don’t get any power.

After that we will check Type C power Ic U3200 under the microscope, we can clearly see there is a burnt mark or we can say hole on u3200.

You can watch some more information on same kind of repair here

Find our another blog on macbook repair here

How we will remove and replace the Type C power management IC U3200?

To remove the ic and put new one, these type of repair involve micro soldering skills. Before replacing the ic we will remove the heat sink. Then we will cover other components with heat resist tape and put some flex and set the right temperature so it will come out easily.

After removing the power IC U3200 clean the excessive solder with flat tip soldering iron and isopropyl alcohol. Before putting the new ic put some flex, set the right orientation and temperature after that put the new power ic U3200.

After replacing the ic we will check the board again with Type C amp meter, now we are getting 19V and 3A. We got the display after replacing the power

management ic u3200.

Macbook pro A1708 dead, Type C power IC replacement Hamilton New Zealand

If you are interesting in learning these sorts of repair or if you have any macbook which have no display you can contact us.

Get your macbook fixed by professionals at applefix call now 078394188 for free quote 125 ward street hamilton.

Macbook Air A1466 turns on but no display backlight repair

Macbook Air A1466 turns on but no display backlight repair

Macbook Air A1466 turns on but no display backlight repair hamilton new zealand

Macbook turns on, you can hear a sound but no display. This is a common issue in Macbook from year 2013 to 2017.  What’s wrong with it? It’s starting up but no display.

When you hardly see apple logo when you start your macbook then most problably it is backlight issue. Plug in your charger, you can see adapter sense is working which is green and you can hear a sound & fan is spinning that means there is nothing wrong with SMC chip but no display which means it’s a backlight problem.

Watch our full youtube video on macbook A1466 backlight repair here



How we will diagnose the problem?

Firstly, we will check the backlight fuse. Let’s put the multi-meter in continuity mode and check the backlight fuse. If backlight fuse is fine then check the other capacitors near the backlight. If the capacitors near the backlight is all good. Then, check the lcd connectors. If you see a red trigger i.e. macbook is liquid damage.

You can watch some more information on same kind of repair here

Find our another blog on macbook repair here

Macbook a1466 turns on but no display backlight repair at applefix hamilton new zealand

After that we have to check the lines. Firstly, we would like to check the J8300 lcd fcp connector, check the two backlight terminals which are SOSW_LCDBKLT. Before that we have to turn on macbook and check with multi-meter and we are getting 1.9V which is way lower than what we should get on backlight. Backlight won’t turn on 1.9V. We are not getting enough power that’s why macbook Air A1466 turns on but no display backlight repair

Backlight is directly connected to (U7701). We can clearly see the board is moisture damage.

We can clearly see the moisture damage and burnt part near the backlight ic. So next thing what we should do is to heat the backlight ic and remove it and put the new backlight ic.

Macbook logicboard repair specialist in hamilton New Zealand

These types of repairs involves micro soldering skills. Once backlight ic is taken out. We have to clean the pads using lot of flux with flat tip soldering iron. Cleaning of the pads is important before putting the new backlight ic. Set the temperature and put the new backlight ic. After replacing the ic, we got the display on macbook A1466.

If you are interesting in learning these sorts of repair or if you have macbook which have no display you can contact us.

Get your macbook fixed by professionals at applefix call now 078394188 for free quote 125 ward street hamilton

iphone gone dead after screen replacement

iphone gone dead after screen replacement

iphone gone dead after screen replacement hamilton new zealand

iPhone 8 gone dead or not charging even after screen replacement, iphone gone dead after screen replacement why has it happened?
This is the most common issues with iPhone 8 and iPhone 8+ that it is not working after a screen replacement.
This is the most well-known mix-up that professional do yet really charging mosfet q3200 of iPhone 8 and iPhone 8+ is excessively near battery terminal and need to separate the battery connectors when we are replacing the screen. A large portion of the professional did the mix-up accidentally or unknowingly because they might do not know that without separation of battery connector it will not going to charge.

You can watch some more information on same kind of repair here

Find our another blog on iphone screen repair here

Watch full youtube video

As it is unmistakably appeared in the below video that how to disconnect them and how close they are.
This charging is significant in light of the fact that it has a SGA association line which is straightforwardly associated with the battery terminal and there is I2C line which is most significant part to turn on or charge the phones.
be cautious while fixing iPhone there are too little parts to deal with so there is a likelihood that you destroyed with your phones so be cautious however there could be other issue too.

iphone gone dead after screen replacement

iphone gone dead after screen replacement

iphone gone dead after screen replacement why?

The following is the connection to a full video on iPhone 8 if it’s not working even after screen replacement
If your iPhone 8 has experienced with this sort of touch issue carry it to apple-fix or call 078394188. If you do not live in Hamilton, you can send your gadget discover guidelines here.
We likewise offer rationale board fix courses and if you find it interesting or interested to learning these aptitudes discover data here or contact us.

get your iphone fixed by professionals at applefix call now for free quote 125 ward street hamilton or call 078394188

iphone x touch not working fix even after screen replacement

iphone x touch not working fix even after screen replacement

iphone x touch not working fix even after screen replacement hamilton

We heard about iphone 6 plus touch disease may be same is happening with iphone x touch not working fix even after screen replacement we know from iphone x has interposer board. Interposer is a middle frame layer which connects upper and lower board of iphone x. See in the below picture

iphone x touch not working fix even after screen replacement

iphone x touch not working fix even after screen replacement

Why the engineers came up with this type of design? To get more space for the battery so that they can use bigger batteries in iphones which can last longer. But doing so there came some disadvantages to end user which is these types can breaks easily in an event of impact.

This blog is about the iphone x which had an impact damage. Screen was broken and no display. Even though new screen was fitted got display but still touch not working.

iphone x touch not working even after screen replacement solutions

If you are a iphone repair shop you need to have proper tools and expertise and skills to carry out this kind of repair. To start with check touch connectors on iphone x if there are any burnt components like capacitors or fuses. It will be an easy repair is the damage is visible without taking apart iphone x interposer board. if there is no damage found then you have to separate. Both of iphonex x upper and lower board are soldered together with a middle layer. You need iphone x board separator apparatus.

iphone x touch connector are located on lower board and part of the touch circuit on upper board. From our experience in an event of impact the touch lines which are connected to upper board dislocate or break resulting touch stopped working.

In the above case iphone x touch problem can be fixed by desoldering the iphopne x board reball them and join together. If the impact is bad enough to pull the pads off interposer then it become a difficult repair. iphone x touch repair is not limited to only interposer layer but it could be related to other components aswell

Below is the link to a complete video on iphone x touch not working fix even after screen replacement

If your iphone x has encountered with this type of touch problem bring it to applefix or call 078394188. If you dont live in hamilton you can send your device find instructions here

We also offer logic board repair courses if you interested learning these skills find information here
